Handling Robots
The Handling Robot is an advanced automated solution designed to streamline material handling tasks across various industries. Equipped with state-of-the-art sensors, precise actuators, and sophisticated software, this robot ensures efficient, accurate, and safe handling of materials, contributing to enhanced productivity and reduced labor costs.
Technical Parameters
| Basic Parameters | Degrees of Freedom | 6 |
|---|---|---|
| Specified Load | 4kg | |
| Usage environment | 0-50℃, 20-80%RH | |
| Body Mass | 25kg | |
| Repeatability | ±0.1mm | |
| Installation Method | ground | |
| Battery Capacity | 2.0 K | |
| Voltage | 220V | |
| Brake | J2, 3 with brake |
| Range of Motion | Maximum Reach at P | |
|---|---|---|
| Minimum Reach at P | ||
| J1 | ±165° | |
| J2 | -100° ~ +120° | |
| J3 | -60° ~ + 150° | |
| J4 | ±175° | |
| J5 | -30°~+130° | |
| J6 | ±180° |
| Maximum Speed | J1 | 260°/s |
|---|---|---|
| J2 | 250°/s | |
| J3 | 250°/s | |
| J4 | 250°/s | |
| J5 | 200°/s | |
| J6 | 600°/s | |
| Speed | 1.5 m/s |
| Other | Main Purpose | welding/discharging/ painting and etc. |
|---|
| Protection Grade | Protection Grade | body IP53,wrist Ip54 |
|---|
